QUARD 400

QUARD 400-sheet-plate

Unisteel and Engineering are one of the leading suppleir QUARD 400 500 put on Abrasion Resistant Sheet Plates suppliers, producer and Exporters. we are authorized shippers of QUARD four hundred and 500 plates in India. QUARD metallic is the main organization situated in Sweden which produces these wear plates of QUARD 400 and 500. QUARD four hundred and 500 is utilized to persevere states of overwhelming wear and whilst exceptional nice and splendid weld potential is needed. QUARD 400 is applied in packages, as an example, loader cans, mining truck bodies, sporting parts of farming machines, wearing components of mining machines, squander expulsion tools and urban vans, put on plates, where requests on put on obstruction are excessive. by means of using QUARD 400 extra slim measurements can be applied and generally speakme car weight brought down, in this manner empowering accelerated payloads.

QUARD 400 500 put on Abrasion Resistant Sheet Plates is used to preserve conditions of overpowering put on and while outstanding trength and tremendous weld restriction is required. QUARD four hundred 500 wear Abrasion Resistant Sheet Plates is used as a chunk of employments, as an instance, loader booths, mining truck bodies, sporting parts of provincial machines, wearing parts of mining machines, waste ejection apparatus and solid vans, wear plates, wherein asks for on put on obstruction are high. QUARD four hundred 500 wear Abrasion Resistant Sheet Plates progressively narrow estimations can be used and general automobile weight reduce down, along these traces permitting prolonged payloads. We preserve up all the sizes and thickness of QUARD 400 & 500 put on Abrasion Resistant Sheet Plates from 03mm ~ 16mm thickness. QUARD 400 & 500 put on Abrasion Resistant Sheet Plates we offer beautiful, lower cost yet the high-quality association. as it should be to that our attestation account these days is in various countries like Egypt, South america Saudi arabia, Thailand,Kuwait,Kazakhstan, Qatar, Oman, Yemen, UAE, Iran, Turkey, Greece, Singapore, Indonesia, Vietnam, South Africa,Brazil, India, Australia.

SPECIFICATIONS of QUARD 400 Plates / Sheets :


Item Abrasion Resistant Plate
QUARD Plates Length Up to 12000 mm
QUARD Plates Production Hot-Rolled (HR) / Cold-Rolled (CR)
QUARD Plates Width 1500 – 2500 mm
QUARD Plates Thickness 0.1 – 100 mm
Heat Treatment N, Q+T
Certificates ISO9001:2000
Material QUARD 400 Plates, QUARD 400 Abrasion Resistant Steel Plates, QUARD 400 Wear Resistant Plates
Payment Terms Paypal, Western Union, T/T (Telegraphic Transfer or Wire Transfer), L/C or Trade Assurance 30% deposit & balance before shipping
Free Sample Yes if we have in stock
Value Added Services Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing
QUARD Plates Origin & Mills Japanese, Indian, USA, Korean, European, Russian, Ukraine (Strictly No China)
Inspection and Test Reports EN 10204 , Mill Test Certificates, Chemical Reports, PMI Test Reports, Mechanical Reports, Third Party Inspection, NABL Approved Lab, Visual Inspection, Destructive Test and Non Destructive Test Reports
Marking
  • Specification
  • Grade
  • Nominal QUARD Plates Sizes
  • QUARD Plates Schedule or Thickness
  • Manufacturing Method (HR / CR)
  • Heat Number
  • Manufacturer’s Name or Custom Logo – on request
  • Marked QUARD Plates Sample: QUARD Plates
Outside Finish Finish as per customer Requirements
Packing of QUARD Plates Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests
Specials Sizes and Specifications other than above can be on request
QUARD 400, 450, 500 Plates Application & uses
  • Petroleum
  • Chemical plant
  • Power sector
  • Gas Industry
  • Hardware tools
  • Metallurgy
  • Machinery
  • Construction
  • Shipbuilding

SIZE of QUARD 400 PLATES / SHEETS :


Thickness Width
Quard 400 4–50 mm 1,500–3,100 mm
Quard 450 3.2–64 mm
Quard 500 4–64 mm
Quard 550 6-30 mm

Hardness of QUARD 400 Plates / Sheets :


  Hardness
Quard 400 HBW = 370–430
Quard 450 HBW = 420–480
Quard 500 HBW = 470–530
Quard 550 HBW = 520–580

QUARD 400 PLATE PROPERTIES :


Brand Manufacture/Co HARDNESS RANGE C.E.V. Typical Values
Values for AR 400 Thk: 10 – 20 - -
Hardox 400 SSAB 370-430 0.37
QUARD 400 DUFERCO 370-430 0.42
JFE EVERHARD 360LE JFE STEEL CORPN. 360-430 0.38
SUMIHARD K400 SUMITOMO METALS 400-440 0.46
ABRAZO 400 TATA UK LTD. 360-430 0.43
RAEX 400 RUUKKI 360-430 0.43
DILLIDUR 400V DILLINGER HUTTE 370-430 0.43
XAR 400 THYSSEN KRUPP 370-430 0.43
BRINAR 400 ILSENBURGER GROBBLECH 360-430 0.48
FORA 400 INDUSTEEL 360-430 0.48
HARDPLAST 380 ISD HUTA 360-430 0.56
NICRODUR 400 ACRONI 360-430 0.56
CREUSABRO 4800 INDUSTEEL 360-430 0.48
WELHARD 400 NSC/JAPAN 400-440 0.46
BIS Plate 320 Bisalloy Steels Pty Ltd 320-360 0.4
BIS Plate 400 Bisalloy Steels Pty Ltd 370-430 0.4
BIS Plate 450 Bisalloy Steels Pty Ltd 425-475 0.48
Rockstar 400 Essar Steel India Ltd. 370-430 0.45
Rockstar 450 Essar Steel India Ltd. 425-475 0.52
Rockstar 500 Essar Steel India Ltd. 450-540 0.6
Abrex 400 NSSMC 360-440 0.4
Abrex 450 NSSMC 410-490 0.5
Abrex 500 NSSMC 450-550 0.55
Abrex 600 NSSMC 550-650 0.73

Equivalent Grades of QUARD 400 Plates / Sheets :


Designation Available thickness mm Feature
Hardness Application and processing features
QUARD 400 6-100 Approx. HB 400 High abrasion resistance and weldability

Chemical Composition of QUARD 400 Plates / Sheets :


Grade C Si Mn P S Cr Ni Mo B
Quard 400 ≤ 0.16 ≤ 0.70 ≤ 1.60 ≤ 0.025 ≤ 0.010 ≤ 0.50 ≤ 0.25 ≤ 0.25 ≤ 0.005

Mechanical Properties of Quard 400 Plates / Sheets :


Grade Yield Strength (MPa) Tensile Strength (MPa) Elongation (%) Hardness Charpy-V impact test
Quard 400 1050 1250 10 HBW = 370 - 430 longitudinal at -40°C 30 J


tolerances and surface properties of Quard 400 Plates / Sheets :


Indicator
Flatness EN 10029: class N (standard) и class S
Thickness tolerance Meet and exceed EN 10029.
Tighter tolerances upon request
Shape, length, width and thickness tolerances Comply with EN 10029
Surface properties Exceed existing market standards EN 10163-2 Class B3


Quard 400 Plates / Sheets Price (As per demand and manufacturer):


QUARD Plates Price
QUARD Plates price US $1,000.00-$3,200.00 / Ton
QUARD Abrasion Resistant Steel Plates US $800.00-$3,000.00/ Ton
QUARD Wear Plates US $800.00-$5,800.00/ Ton
QUARD High Tensilee Strength Steel Plates US $1,299.00-$1,999.00/ Ton
QUARD High Strength Plates US $1,100.00-$5,000.00/ Ton


Testings (Destructive, Non Destructive):

  • Positive Material Identification - PMI Testing
  • Chemical Analysis - Spectro Analysis
  • Mechanical Testing Such as Tensile, Elongation, Reduction of Area
  • Micro Test
  • Macro Test
  • Hardness Test
  • Pitting Resistance Test
  • Intergranular Corrosion (IGC) Test
  • Flaring Test
  • Flattening Test
  • Hydrostatic Test
  • Hydrogen-Induced Cracking (HIC) Test, NACE TM0284
  • Sulfide Stress Corrosion Cracking (SSC), NACE TM 0177
  • Radiography Test
  • Dye Penetrant Test (DP Test)
  • Ultra Sonic Test (UT)
  • Eddy Current Testing
  • Impact Test
  • Bend Test

Packing :

We DUPLEX STEEL & ENGINEERING Ensure the best quality of Packing, because its play important role especially in a case of international shipments in which consignment pass through various channels to reach the ultimate destination, so we put extraordinary concern regarding packaging.

We pack our goods in numerous ways based on the products. We pack our products in multiple ways, such as:--

  • Boxes and Crates
  • Shrink-wrapped
  • Carton boxes
  • Wooden pallets
  • Wooden boxes
  • Wooden crates

APPLICATION :

  • Chemical tanks
  • Pulp & Paper Industries
  • Petrochemical Industries
  • Power Generation Industries
  • Oil & Gas Industries
  • Desalination
  • Architecture and Construction
  • Food Processing Equipment
  • Biofuels plant
  • Cargo tanks for ships and trucks
  • Chemical Industries Pumps, fans, centrifuges, sulphur melting coils,
  • Digester in sulphate and sulfite plants, blow tanks, blow lines
